Philips 55BDL4511D/00 55″ Signage Digital A-board Display with 500nit Brightness and 4K Ultra HD Black 24/7

Philips 55BDL4511D/00 55″ Signage Digital A-board Display with 500nit Brightness and 4K Ultra HD Black 24/7

55BDL4511D/00

  • Indoor Digital A-board Black
  • 139.7 cm (55″) 3840 x 2160 pixels 500 cd/m²
  • 8 ms
  • Ethernet LAN
  • Built-in speaker(s) 20 W
-
+

Details

Operate, monitor and maintain with CMND & Control Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100. FailOver ensures content is always playing From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on. SmartPower for energy saving The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs. Schedule what you want, when you want with SmartPlayer Turn your USB into a true cost effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display.Create your playlist and schedule your content via the on screen menu, and enjoy your own created playlists anytime, anywhere. ADS wide-view panel display Be seen from any angle with ADS wide-view technology. Advanced Super Dimension Switch delivers faster on-display picture processing for smoother content transitions, remarkable image accuracy, and superior colour reproduction with 180 degree viewing. Optional OPS Slot Open Pluggable Specification is an industry standard slot in to which you can add an OPS-compatible media player. This gives you the ability to upgrade or change your hardware whenever you need. Turning your display in to an all-in-one digital signage solution has become simplicity personified.

System Integration

Please ask about how we can configure your solution

Global Operations

We ship and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Specification

Display
Panel type VA
Display diagonal 139.7 cm (55″)
Display resolution 3840 x 2160 pixels
Display brightness 500 cd/m²
HD type 4K Ultra HD
Touchscreen No
Native aspect ratio 16:9
Response time 8 ms
Contrast ratio (typical) 5000:1
Contrast ratio (dynamic) 500000:1
Viewing angle, horizontal 178°
Viewing angle, vertical 178°
Display number of colours 1.07 billion colours
Pixel pitch 0.315 x 0.315 mm
Display diagonal (metric) 138.7 cm
Panel life 50000 h
Haze rate 25%
Ports & interfaces
HDMI ports quantity 3
HDMI version 2.0
HDMI input ports quantity 2
HDMI output ports quantity 1
DVI port Yes
DVI-I ports quantity 1
DisplayPorts quantity 2
DisplayPorts in 1
DisplayPorts out 1
USB port Yes
USB ports quantity 2
USB version 2.0
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
Audio (L/R) in 1
Audio (L/R) out 1
RS-232C Yes
Remote (IR) input 1
Remote (IR) output 1
OPS module slot Yes
Audio
Built-in speaker(s) Yes
Number of built-in speakers 2
RMS rated power 20 W
Design
Product design Digital A-board
Placement supported Indoor
Orientation Horizontal/Vertical
Product colour Black
VESA mounting Yes
Panel mounting interface 400 x 400 mm
Bezel width (bottom) 1.39 cm
Bezel width (side) 1.39 cm
Bezel width (top) 1.39 cm
Performance
Purpose Commercial
Operating hours (hours/days) 24/7
Power
Power consumption (typical) 135 W
Power consumption (standby) 0.5 W
Power consumption (sleep) 0.5 W
Energy efficiency class (SDR) G
Energy consumption (SDR) per 1000 hours 136 kWh
AC input voltage 100 – 240 V
AC input frequency 50 – 60 Hz
Energy efficiency scale A to G
Computer system
Video formats supported H.263, H.264, H.265, MPEG
Audio formats supported AAC, HE-AAC
Image formats supported BMP, JPG, PNG
Weight & dimensions
Display width 1241.8 mm
Display depth 63.6 mm
Display height 712.6 mm
Display weight 16.6 kg
Packaging content
Remote control included Yes
Batteries included Yes
Cables included AC, DisplayPort, IR sensor, RS-232
Operational conditions
Operating temperature (T-T) 0 – 40 °C
Operating relative humidity (H-H) 20 – 80%
Storage temperature (T-T) 0 – 60 °C
Storage relative humidity (H-H) 5 – 95%
Logistics data
Harmonized System (HS) code 85285210
Screen Size 55"
Aspect Ratio 16:9
Resolution 3840x2160
Brightness 500nit
Viewing Angle 178/178 (H/V)
Speaker Yes
I/O DisplayPort, DVI, HDMI, RJ45, RS232, USB
Operating Temperature 0°C to 40°C
Operating Humidity 20% to 80%
LAN Yes
