Axiomtek DSP600-211 4K Digitagal Signage Computer with AMD Ryzen V1000 Series

Axiomtek DSP600-211 4K Digitagal Signage Computer with AMD Ryzen V1000 Series

DSP600-211

  • AMD Ryzen Embedded V1000 series
  • 2 x DDR4-2400 SO-DIMM for up to 32GB of memory
  • 4 x HDMI 2.0 with 4K resolution
  • 4 x USB, 2 x GbE LAN
  • 1 x M.2 Key E 2230 for Wi-Fi/BT
  • 2 x M.2 Key M 2280 for storage

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

-
+

Details

The Axiomtek DSP600-211 is a 4K Digital Signage Computer with AMD Ryzen Embedded V1000 series. This Computer contains Two DDR4-2400 SO-DIMM for up to 32GB of memory along with two M.2 Key M 2280 for storage. There is one M.2 Key E 2230 for Wi-Fi/BT and four HDMI 2.0 with 4K resolution. It also includes four USB ports and two GbE LAN.

Ordering Info

DSP600-211-V1807B AMD Ryzen Embedded V1807B
DSP600-211-V1605B AMD Ryzen Embedded V1605B
DSP600-211-V1202B AMD Ryzen Embedded V1202B

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We ship and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Processor Type 4 Cores, AMD Ryzen
Memory Capacity Up to 32GB
Serial Ports (COM) 2 Ports, 2 Ports, Any COM Type, RS-232
USB Ports 2 Ports, 2 Ports, 4 Ports, Any USB Speed, USB 2.0, USB 3.0
Ethernet Ports (LAN) 1G, 2 Ports, 2 Ports, Any LAN Speed
Wireless Cellular, Wi-Fi
Video Ports 4 Ports, 4 Ports, Any Video Type, HDMI
Storage Type 2, 2, Any Storage Type, M.2 SATA
Expansion Type 2, 2, Any Expansion Type, M.2
Input Voltage 12 VDC
Mounting Options VESA-mount, Wall-mount
Operating Temperature 0°C to 40°C, 0°C to 45°C, Standard
Market Certifications CE/FCC
OS Support Linux, Windows 10, Windows 10 IoT, Windows 10 Pro
