Giada D611 Intel Core i3/i5/i7 UP3 8K Display High-End Digital Signage Player

Name: Giada D611 Intel Core i3/i5/i7 UP3 8K Display High-End Digital Signage Player
SKU: D611
Availability: InStock

Giada

Giada D611 Intel Core i3/i5/i7 UP3 8K Display High-End Digital Signage Player

End of Life

1 x DP, 2 x HDMI, Supporting 8K Display
2 x SO-DIMM DDR4 Memory, Up to 32GB
1 x M-key M.2 (2242/2280) for SSD
Supporting RJ45, WiFi 6(CNVi), 3G/4G/5G Ethernet Access

Discontinued
This product is end of life. There may still be stock available; please contact us for more information or suitable replacement solutions.

Product Code: D611

Categories: End Of Life Products

Range: Giada

Details

The Giada D611 Tiger Lake UP3 High-end Digital Signage Player is driven by Intel Core i3/i5/i7 with Intel 11th G UHD Graphics supporting 8K Display via 1 x DP and 2 x HDMI and 2 x SO-DIMM DDR4 Memory up to 32GB, shipping with multiple I/O including 1 x USB 3.2 Gen2, 2 x USB2.0, 1 x USB Type-C3.2 Gen2 and RS232.

Downloads

Datasheet (D611) (PDF)

0.46MB

System Integration

Please ask about how we can configure your solution

Global Operations

We ship and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Processor Type	4 Cores, Intel Core
Memory Capacity	Up to 32GB
Serial Ports (COM)	1 Port, 1 Port, Any COM Type, RS-232
USB Ports	2 Ports, 2 Ports, 4 Ports, Any USB Speed, USB 2.0, USB 3.2
Ethernet Ports (LAN)	1 Port, 1 Port, 1G, Any LAN Speed
Wireless	Cellular, Wi-Fi
Video Ports	1 Port, 2 Ports, 3 Ports, Any Video Type, DisplayPort, HDMI
Audio	Yes
Storage Type	1, 1, Any Storage Type, M.2
Expansion Type	2, 2, Any Expansion Type, M.2
Input Voltage	12-19 VDC
Mounting Options	VESA-mount
Operating Temperature	0°C to 40°C, Standard
Market Certifications	CE/FCC
OS Support	Windows 10, Windows 10 IoT, Windows 10 Pro
