Neousys Nuvo-2700DS AMD Ryzen Rugged, 4x 4K Interactive Digital Signage Computer

Nuvo-2700DS

AMD Ryzen embedded V1605B series quad-core 15W CPU
Rugged -25°C to 70°C fanless operation
4x 4K DP display, 3840 x 2160 resolution per output
AI inference capability by 2x optional Edge TPU
1x M.2 3042/3052 B-Key for 4G/5G module
2x USB3.1 Gen 1 and 2x USB2.0
8V to 35V wide-range DC input with built-in ignition power control
Flexible power input options: mini-DIN or terminal block

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

I require customisation *
Please share some background information on your project to help us ensure we’re proposing the best solution *
What processing level is required? *
How much RAM do you require? *
How much storage is required? *
What is the project timeline? *
What operating system would you like to use? *
Do you need any Wi-Fi or Cellular? *
- Wi-Fi
- Cellular
Do you need wide-temperature components? *
- Yes
- No
Do you need a mounting kit? *
Do you need an AC-DC power supply? *
Do you need any additional expansion modules? *

Product Code: Nuvo-2700DS

Categories: Digital Signage Computers, Digital Signage Players, PC's

Details

The Neousys Nuvo-2700DS series is a rugged digital signage system with AI inference capability for personalized user experience and audience measurement. Powered by AMD Ryzen Embedded V1605B, it can output to four 4K displays and playback 4K H.265 videos at 60fps. By supporting two Google Edge TPUs, it delivers a total of 8 TOPS AI inference performance in a fanless compact form factor. The wide operating temperature and fanless design make it ideal for 24/7 applications in harsh indoor and outdoor environments, such as flight information display system (FIDS) or train schedule board. Furthermore, Nuvo-2700DS can also be deployed for mobile applications due to the inclusion of ignition power control and full bandwidth support of WIFI 6, 4G LTE, and 5G network modules. The support of two Google Edge TPUs empower Nuvo-2700DS as a smart digital signage player to leverage real-time camera input and AI computer vision models (e.g., YOLO-lite or PoseNet) to offer audiences an interactive and personalized experience. Besides, it can get to know its audience by collecting anonymous data from people counting, body gesture recognition, facial recognition, attention measurement, and emotion analysis. The Nuvo-2700DS series signifies a new age of AI enabled digital signage player for harsh environments and mobile applications. You can utilize Nuvo-2700DS as a video wall player to playback to 4K ultra high definition visual displays or deploy Nuvo-2700DS as a low power fanless Edge AI platform for emerging AI applications. With AI inference from Google Edge TPUs, Nuvo-2700DS creates an interactive and personalized experience, but moreover, it can quantify offline campaign like never before and offer insight data.

Ordering Info

Nuvo-2700DS	AMD Ryzen Embedded V1000 rugged 4x 4K interactive digital signage system
Nuvo-2700DS-1TU	AMD Ryzen Embedded V1000 rugged 4x 4K interactive digital signage system with 1x Google Edge TPU
Nuvo-2700DS-2TU	AMD Ryzen Embedded V1000 rugged 4x 4K interactive digital signage system with 2x Google Edge TPU

Downloads

Datasheet (Nuvo-2700DS) (PDF)

0.48MB

System Integration

Please ask about how we can configure your solution

Global Operations

We ship and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Processor Type	4 Cores, AMD Ryzen
GPU	Integrated GPU
AI Engine	Google AI Solutions
Memory Capacity	Up to 64GB
Cooling Type	Fanless
Serial Ports (COM)	2 Ports, 2 Ports, Any COM Type, RS-232
USB Ports	2 Ports, 2 Ports, 4 Ports, Any USB Speed, USB 2.0, USB 3.1
Ethernet Ports (LAN)	1G, 2 Ports, 2 Ports, Any LAN Speed
Wireless	Cellular, Wi-Fi
Video Ports	4 Ports, 4 Ports, Any Video Type, DisplayPort
Digital I/O	8 DIO
Audio	Yes
Storage Type	1, Any Storage Type
Expansion Type	2 Ports, 2 Ports, 4 Ports, Any Expansion Type, M.2, Mini PCI Express
Input Voltage	12 VDC, 8-35 VDC
Mounting Options	Wall-mount
Operating Temperature	-25°C to 50°C, -25°C to 70°C, Extra-Wide
Market Certifications	CE/FCC, MIL-STD
OS Support	Linux, Windows 10, Windows 10 IoT, Windows 10 Pro, Windows 11, Windows 11 IoT, Windows 11 Pro
