Vestel EA32C-1D 32″ Digital Signage Display

Name: Vestel EA32C-1D 32″ Digital Signage Display
SKU: EA32C-1D
Availability: InStock

Vestel EA32C-1D 32″ Digital Signage Display

End of Life

Resolution : 1920×1080 (FHD)
Brightness : 350 cd/m2
Operation : 16/7
Bezel : 21-25 mm (T/R/L), 13-16 mm (B)
Interface : HDMI 2.0 / DP 1.2A / USB /RS232 / RJ45 / Audio / Speaker
Application Area: Retail

Discontinued
This product is end of life. There may still be stock available; please contact us for more information or suitable replacement solutions.

Product Code: EA32C-1D

Categories: 2K Resolution Displays, End Of Life Products

Range: Vestel Commercial Displays

Details

The EA32C-1D is a 32″ Digital Signage Display.

The EA32C-1D is made available to set any Source on startup of the display. It can also be switched on any other signal source using scheduler and failover scenarios. This lets the users to freely control the process of their requirements allowing best user experience. The Digital Signage Monitor Software allows many important features such as Scheduler. Scheduler sets your display turn on/off time easily and lets you not to worry about the status of your displays in any time.

Pixel Shifting is designed to be activated inside the SoC in order to prevent for potential risk of image sticking, caused by constant content. With this feature turned on, pixels on the screen will move in an interval while causing no interference of visual experience. The SoC Software has a protection for “No Signal” scenario. If the USB is unplugged after your content is set to be displayed with USB, the display will either show your customised banner or search for any other signal from other sources (HDMI, Display Port, etc.). This failover protection is constructed for higher user experience.

Downloads

Datasheet (EA32C-1D) (PDF)

3.07MB

System Integration

Please ask about how we can configure your solution

Global Operations

We ship and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Screen Size	32"
Aspect Ratio	16:9
Resolution	1920x1080
Brightness	350nit
Viewing Angle	178/178 (H/V)
Speaker	Yes
I/O	DP, HDMI Input, RJ45, RS232, USB
Mounting	VESA
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90%
Wi-Fi	Yes
OS	Linux
